Cixi WJ245-5.0-05P-11A-00A Spring-loaded terminal

Name: Cixi WJ245-5.0-05P-11A-00A Spring-loaded terminal
SKU: WJ245-5.0-05P-11A-00A
Price: 6.83 GBP
Availability: InStock

£6.83

Multi Buy

Please choose

In stock: 360 available

Product Details

Cixi WJ245-5.0-05P-11A-00A Spring-loaded terminal

CS 5 mm

No. of rows 1

Pins per row 5

Number of pins 5

Series DG245

Min. stripping length 5 mm

Stripping length (max.) 6 mm

Connection Spring-loaded terminal, Print

Nominal current 15 A

Cross section (flexible) (min.) 0.08 mm²

Nominal current - rounded value 15 A

Cross section (inflexible) (min.) 0.08 mm²

Cross section (flexible) (max.) 3.31 mm²

Cross section (inflexible) (max.) 3.31 mm²

AWG (min.) 28

Connector orientation At an angle (to the PCB)

AWG max. 12

Contact material Phosphor bronze tin plated

Enclosure material Polyamide 6.6

Factory colour Grey

Wire protection Yes

Actuation direction At an angle (to the PCB)
